83.82.0.240.0000 Star Delta Single Timer Relay

Giá: Liên hệ

Model: 83.82.0.240.0000

Nhà sản xuất: FINDER

Xuất xứ: EU/G7

Danh mục: FINDER

74 Trịnh Đình Thảo, Phường Phú Trung, Quận Tân Phú, Thành phố Hồ Chí Minh, Việt Nam
0909 057 026
(028) 3853 6931
info@pumptech.vn

Manufacturer:FINDER

Manufacturer Part No: 83.82.0.240.0000

ATTRIBUTE	VALUE
Supply Voltage	24 → 240 V ac/dc
Time Range	0.05-10 d, 0.05-10 h, 0.05-10 min, 0.05-10 s
Mode of Operation	Star Delta
Mounting Type	DIN Rail
Number of Timer Functions	Single
Number of Contacts	2
Series	83 Series
Time Increment	Days, Hours, Minutes, Seconds
Power Supply	External
Contact Configuration	DPNO
Current Maximum	16 A
Minimum Voltage	16.8 V ac/dc
Maximum Voltage	265 V ac / V dc
Depth	100.3mm
Width	22.5mm
Contact Material	Silver Nickel
Length	78.8mm
Minimum Operating Temperature	-20°C
Switch Configuration	DPDT-NO
Maximum Operating Temperature	+60°C
