Manufacturer	FINDER
Type of relay	electromagnetic
Contacts configuration	3PDT
Rated coil voltage	24V DC
AC contacts rating @R (at resistance load)	10A / 250V AC
DC contacts rating @R (at resistance load)	10A / 30V DC
Contact current max.	10A
Switched voltage	max 220V DC, max 400V AC
Relay variant	industrial
Mounting	socket
Relay series	60.13
Operating temperature	-40…70°C
Body dimensions	36.4 x 32.5 x 54.2mm
Coil resistance	445Ω
Coil current	53.9mA
Contact material	AgNi
Coil power consumption	1.3W
Leads	stud terminals
Number of pins	11
Electrical connection	round socket
Kind of connector	undecal
Related items	90.03, 90.13, 90.15, 90.15.1, 90.21, 90.23, 90.27, 90.83.3
